1、 PLC控制系統，大液晶觸摸屏，動態顯示折疊狀態，可實現人機對話功能，內儲多套自動折疊程序。PLC control system, intelligent touch screen, dynamic display folding condition can realize man-machine dialog and reserve sets of folding program.
2、 兩橫三縱折疊功能，前三折用氣刀，后兩折用機械折刀。Two horizontal with three vertical function, first 3 step by pneumatic fold, later two step by mechanical folding knife.
3、 兩套獨立的驅動電機，由變頻器控制，折疊速度在50米/分鐘內無極可調功能，每小時可最多折疊1000條床單。Two sets of independent drive motor control by inverter, it is infinitely adjustable function within 50 meters/min folding speed per hour can realize fold article 1000 sheets per hour.
4、 高品質的靜電消除棒，所有導布輥都做了特殊的防靜電處理，有效減少布草上的靜電，降低了布草起卷，起皺等問題，提高折疊率，增加機器的可靠性和穩定性。 High quality anti-static eliminate stick, all the guide roller with special destabilization to reduce static from linen effectively. Reduces clothes grass wrinkles and enhance the rate of folding, increase the reliability and stability of the machine.
型號規格 Model | ZD-3000 | ZD-3300 |
最大折疊寬度 (mm) Maximum folded width | 3000 | 3300 |
最多折疊層次 Maximum folding levels | 5/32 | 5/32 |
最大折疊速度 (m/min) Folding speed | 50 | 50 |
額定電壓 (v/Hz) Rated voltage | 380/50 | 380/50 |
電機功率 (kw) Motor power | 1.87 | 1.87 |
整機重量 (kg) Overall weight | 1430 | 1630 |
外形尺寸 (mm) Exterior dimension | 4160*2930*1750 | 4460*293*1750 |
